NPS-H Non-bitumen-based polymer self-adhesive film (pre-paved) waterproof membrane
The waterproof membrane is made with pre-paved full bonding installation and does not require full bonding of the protection layer and the structure.
1.Product overview
Aichuang NPS-H non-bitumen-based polymer self-adhesive film (prepaved) waterproof membrane is a polymer waterproof membrane that is made by compositing HDPE with water-resistant and ultraviolet-resistant polymer gel with a special process.
2.Product features
① High strength: it can effectively prevent breakage or puncture without a protection layer and can be poured with concrete after being bound with steel reinforcements.
② Full bonding with structural layer: it can form permanent bonding with concrete to achieve high bonding strength and good water locking effect and also can prevent moisture seeping into the structure effectively.
③ Preventing damages caused by foundation settlement to the waterproof layer: with foundation settlement, the protection layer can tear the traditional waterproof layer. The materials with pre-paved full bonding installation can be bonded with structure to avoid damages.
④ Shorter work period: the pre-paved full bonding installation has low requirements for base surface and shortens the work period by 1/3 compared with common membranes.
High strength, high bonding force, transverse-flowing water prevention, convenient application
3.Product classification and specification
|
Thickness |
1.2mm |
1.7mm |
2.0mm |
|
Width |
2000mm |
||
4.Technical data
| NO. | Item | Index | |
| Pre-paved P | |||
| 1 | Tension | Tension/(N/50mm)≥ | 500 |
| Elongation at break of membrane,%≧ | 400 | ||
| Elongation at maximum tension/%≥ | —— | ||
| 2 | Tear strength of nail rod/N≧ | 400 | |
| 3 | Channel control system | 0.6Mpa,no water running | |
5.Applicable scope
Applicable to parts subjected to pre-paved full bonding installation
